Product Description

For the sake of delivering high compatibility, the cases support USB 3.0 natively at its sides, uses a universal optical drive eject button (optional), and uses a unique drive tray. The drive tray pivots for easy drive access, supports variable drive positions for different drive sizes and supports multiple drives.

At 435mm wide and 100mm high, the FC10 is designed to be a large silently cooled PC, able to accommodate big components. It has 2 full height expansion slots*, 2 USB 3.0 ports, and supports a minimum of 5 drives (2×3.5” + 3×2.5”) and a maximum of 11**. The case comes in silver or black.

* A flexible PCI riser is needed to connect any PCI cards to the motherboard.
The lower slot only supports cards up to 190mm long, while the upper supports up to 300mm long.

** Depends on configuration (motherboard size, optical slot and PSU)
A 11 drive setup is 5×3.5” + 6×2.5” drives. It is not possible to fit more than 5×3.5” or 6×2.5” drives.

Chassis Material	Premium Grade (6063) All Aluminium, 4mm Thick Extruded Panels
Drive Capacity	Minimum 2×3.5″+ 3×2.5″, Maximum 5×3.5″ + 6×2.5″*
Optical Drive Bays	1 x Slim Slot Loading Drive
Expansion Slot	2x Full Height Expansion Slots, Flexible PCI-E Riser Required
USB Ports	2x USB3.0, Left & Right Side
Cooling	Heatpipe Direct Touch 4 Pipes – Recommended CPU TDP 65W, Max TDP 95W
Dimension (W x D x H)	435 x 319 x 100mm
Power Supply	Streacom ZF240 or Nano PSU (Not Included)
IR Receiver	Streacom Flirc (Not Included)
Net Weight	5.4KG
Warranty	24 months
